Half-height Sensor Fast Speed Swing Turnstiles Brief Introduction
Technical Parameters:
Product model | AX-HSB001 |
Structure | 304/316 stainless steel |
Housing size | length 1400* width 150* height 990 mm |
Channel width | 600 mm |
Motor voltage | DC 24V |
Control signal | switching signal |
Side indicator | Optional |
Swipe valid indicator light | located in the center of the lid |
Passing speed | 30-45 person/minute |
Read head installation position | 2 |
Control board mounting position | fixed on the turnstile |
Off time | about 0.5-1.5 seconds |
Working temperature | -30 °C to 60 °C |
Relative humidity | ≤90%, no condensation |
Product Features:
Turnstile main control board: with industrial-grade 32-bit ARM chip, leading in the industry, fast response, greatly improving processing capacity Clutch: using electromagnetic clutch device
Operating angle: angle detection and control by angle encoder, accurate to within 1 degree
Operating mode: After swiping the card, the swing arm opens, prompting the pedestrian to pass, and after a pedestrian passes, the swing arm automatically closes
Anti-reverse: after the card is swiped, pedestrians are only allowed to travel in one direction; if they pass in the opposite direction, an alarm will be issued, and in some cases the swing arm will close quickly.
Anti forced entry: when the swing arm is not open, if it is forcibly broken in, the swing arm will be locked at a certain angle and then immediately locked to avoid the problem of the broken arm and the damage of the movement caused by the traditional swing gate.
Speed adjustment: speed can be adjusted according to the requirements of different places, with built-in adjustment switch
Fire fighting mode: after the power is cut off, the product swing arm opens to form an open channel.
Counter function: accurate counting, thanks to the use of angle encoder
Infrared detection: 6 pairs of infrared detection to determine various travel status (infrared quantity can be selected 6-10 pairs)
Automatic reset: After obtaining the permission of the gate, if pedestrian does not pass within specific time, the turnstile automatically cancels the permission and returns to the initial state.
Noise: almost no noise
Power module: Output: DC24V; adopts a new power module, does not cause changes in output voltage due to changes in input power, stable and reliable
Motor: DC24V 30W
Compatibility: With a personalized installation interface, compatible with IC, ID card and other smart cards can be expanded into an automatic identification system. Access control, attendance, charging and other functions can be used in conjunction with other types of channel products: waterproof, sun proof, low and high temperature resistance
It is ok to add temperature measuring facial recognition device on this swing turnstile as below picture:
Shenzhen Anxia Heavy Industrial Co., Ltd. was founded in 2008, which is a professional manufacturer dedicated in the R&D, large-scale production on security system products, such as turnstile gates, barrier gates and car plate recognition systems. As one of the biggest comanies in Shenzhen security system industry for over 10 years, our team is committed to provide high quality products and services. Our products include intelligent parking lot system, automatic access control system, intelligent turnstile system and so on. We have experience on international trading since 2010, and our products sell well in southeast Asia, middle east, east Europe, over 40 countries all over the world. Feel free to contact us if you have projects to do with security systems. We'd love to build a long term cooperative relationship with you.
Our Clients:
Certificate of honor:
Exhibition:
Q1: Do you have English language system?
A: We can sell you with hardware only. Also, if you want with system as well, we have our system supports English language.
Q2: Can we connect your access control system with our system?
A: Yes, we provide SDK and Software development service with connection port.
Q3: Are your turnstile/barrier gates waterproof?
A: Yes, our turnstile/barrier gates have water proof feature.
Q4: Do you have CE and ISO9001 certificate?
A: Yes, our products have passed CE and ISO9001 certificate, and we can send you copy if you want.
Q5: How can we install those turnstile/barrier gates? Is it easy to do?
A:Yes, it's really easy to install, we have done most of the jobs before sending our products. You just need fix the gates with screws, and connect power supply cables and internet cables.
Q6: How about your warranty?
A: Our products are all with one year warranty.
