Stainless Steel Housing Automatic Tripod Turnstile
- Jul 19, 2017 -

Basic Info

  • Certificate: CE, ISO

  • Specification: CE; ISO: 9001

  • HS Code: 8608009000

  • Material: 304 Stainless Steel

  • Direction: Double Ways

  • Transport Package: Wooden

  • Origin: China

Product Description

Turnstile, tripod turnstile



Function and Features:
                                                                                                                1.Special wheel mechanism is used here to realize the function of fixing and also unfixing all the parts of the turnstile
2.All the system runs stable with little noise and no mechanical impact
3.It can self-check and alarm which will be make it convenient to use
4.Several ways of working molds can be chosen at your request
5.It can work bi-direction, or one direction permitted, one forbidden, or one direction charged, one for free, and all the working molds can be set by the buttons in the main control board
6.Beam falling and lifting can be controlled in far distance so to satisfy the special requirement of the users and the request of fire protection
7.Beam can be lifted and fall when electricity is cut-off
8.It has the standard electrical interface which can be connected with various kinds of reader and writer equipment
9.So all the functions can be realized in one integration machine and can be controlled and managed by the computer in the far distance
10.The number of the persons who have passed by can be counted automatically which can also be displayed in LED
11.Direction-guide lights are in the turnstile to tell you which direction can go or which cannot
12.You can set the function with or without card-reading memory according to your requirement
13.The number of the persons who can pass by the turnstile can be set to meet the requirement of some special occasions
14.After reading the card, if the person who punched the card does not pass it within the set time, then this chance to access will be canceled, and the set time can be changed according to your request

Applications:
The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms, clubs, metros, bus stations, high class communities, intelligent buildings, hotels, subway stations and other high level venues, ect.
After-sale Service:
1.5 year warranty
Lifetime Service with charge accordingly



Technical Data
Voltage220V± 10%,110V±10%
Frequency50/60HZ
Control circuitDC12V
Consumption30W
Passing speed≤35Persons/min
Working temperature-20~+55
Communication socketRS485 standard socket/LANsocket
